LARGE DIAMETER FRONT DRIVE SHEAVES
Sheave set supplied with special bronze bushing installed with retainer bolts
5.900" Diameter
___________________________________________________________________
CHOOCHOO RAMP SETS
Manufactured from high quality proprietary tool steel and heat treated to 43/45 rockwell C.
Ramp profile features continuous curve with no defined angle changes to interrupt / stall roller travel.
Close tolerances on stall angle for better car reaction.
Lightweight design is 15 grams/set less than conventional models
20 -- 26 -- 22
18 -- 28 -- 22
15 -- 38 -- 34 -- 22
15 -- 32 -- 28 -- 22
15 -- 32 -- 24
15 -- 30 -- 24
15 -- 30 -- 22
15 -- 28 -- 22
15 -- 26 -- 22
14 -- 36 -- 32 -- 24
14 -- 37 -- 33 -- 24
13 -- 36 -- 32 -- 24
13 -- 36 -- 32 -- 22
13 -- 39 -- 34 -- 24
12 -- 38 -- 34 -- 24
12 -- 37 -- 33 -- 24
12 --36 -- 32 -- 24
12 -- 36 -- 30 -- 24
12 -- 34 -- 31 -- 24
12 -- 33 -- 30 -- 24
12 -- 32 -- 28 -- 22
12 -- 32 -- 24
12 -- 30 -- 37 -- 33 -- 24
12 -- 30 -- 36 -- 32 -- 24
12 -- 30 -- 24
12 -- 28 -- 22
12 -- 28 -- 20
___________________________________________________________________
SPECIAL HARDENED ROLLER SET
Constructed from hardened steel on outside surface with bronze bearing inside.
The perfect mate for our hardened ramps but may be used on standard ramps for better wear.
Available in flat or barrel shaped face.
___________________________________________________________________
ARM BOLT KIT
High strength aircraft 3/16" full diameter bolts -- will not cut into the arms or spring carrier like standard Allen bolts do. Designed for double shear applications.
____________________________________________________________________
CHOOCHOO DRIVE BELTS
9" type offered in many different width's
.....
LH20 ---- .800"-->.835" width
.
LH-SW ---- .850"--.880" width (suits Shockwave clutch)
____________________________________________________________________
WEIGHT KIT
# LH - WK
Complete kit contains six weight sizes -- choice of --> 1 gram -- 2.5 gram -- 3 gram
3.5 gram -- 4 gram -- 4.5 gram -- 5 gram -- 5.5 gram -- 6 gram -- 7 gram -- 8 gram
Supplied in handy plastic carrying case.
--------------------------------
Individual Kits contain six weights of each size
# LH-WK--size
______________________________________________________________________
PRIMARY SPRINGS (front unit)
P113 Orange Spring (50#)
P115 Purple spring (73#)
P117 Green spring (90#)
P120 Black/Yellow spring (105#)
*** spring rates are stated at installed height and may vary from spring to spring.
Shown as reference only.
_____________________________________________________________________
ChooChoo Helix Cams
Our helix cams are offered in a wide variety of configurations in straight and multi angle designs. "Half" holes provided in the middle of the tuning range for fine adjustments.
34 --- 38 --- 38/42 --- 38/42/46 --- 38/43/47 --- 38/44 --- 38/44/48 --- 38/45/49 --- 38/46 --- 38/46/50 --- 38/47/51 --- 38/48 --- 38/48/52 --- 38/50 --- 38/52
________________________________________________________________
SECONDARY SPRINGS
SC010 Standard -- yellow
SC011 Heavy duty -- red
___________________________________________________________________
SECONDARY
__________________________________________________________________________
Posts
 |
 |
Clutch posts in assorted lengths to accommodate different belt width's.
Std -- +15 -- +30 -- +45 -- +55 -- +65 -- +75 -- +85 -- +100
---------------------------------------------------------------------------------------------------------------------------
POST SHIMS
Laser cut for proper fit
Square shims for top of the post to raise the cover -- .005 + .010" thickness
Round shims to adjust fixed pulley for different belt widths -- .005" -- .010" -- .020" thickness
-------------------------------------------------------------------------------------------------------------------------------------------------------
LOCKING NUT AND BEARING
9/16"-18 Threads -- 1.375" bearing outside diameter
